Offline Installation

This guide installs Kamiwaza on a standalone RHEL 9 x86_64 host from a previously published offline bundle. The target does not pull product images during the install. Whether the host bootstrap can also run without any network access depends on the selected bundle: do not call an installation fully air-gapped unless that exact build was tested with disconnected RHEL package sources.

This is an advanced, operator-driven path. If the target has normal internet access, use Online Installation. This page describes the standalone k0s-podman topology; an EKS recipe is not an alternative source of truth for this installation.

An offline deployment has three separate completion levels:

  1. Core installed: the platform is healthy and login works.
  2. Bundle installed: bundled extension images are loaded and the live catalog is imported.
  3. Release parity (publisher qualification): one bundled extension is deployed, verified, and removed through the supported catalog/API path, plus any additional gates recorded by the selected release run.

Do not report level 2 or 3 after only pre-staging the extension catalog. Level 3 requires the private, hash-recorded Kajiya gate inputs from the selected run and is performed by Kamiwaza release engineers; it is not a customer installation requirement. A customer handoff without those internal inputs can complete and report levels 1 and 2.

Before you begin​

You need:

  • A supported RHEL-compatible 9.x x86_64 host that meets the System Requirements.
  • A host name no longer than 54 characters.
  • A Kamiwaza license and access to one immutable release or Kajiya run.
  • A connected staging machine if the target cannot download the artifacts.
  • Root access on the target. For a remote private host, Session Manager (SSM) or an equivalent managed shell is preferred over SSH.
  • Bash 4.4 or newer plus GNU coreutils, findutils, curl, jq, gpg, and tar on every machine that runs the snippets. They use GNU options and do not run in stock macOS Bash; use a trusted Linux staging host or container when the connected workstation is a Mac. If the target has no reachable RHEL repositories, those tools and all OS packages required by the selected prerequisite bootstrap must already be available through a trusted local repository or the verified handoff.

Check the actual filesystems​

The bundle, extracted extensions, container images, and the Rook/Ceph OSD can live on different filesystems. A large virtual disk is not proof that /var/lib or /tmp has room; cloud RHEL images commonly put /var on a small logical volume.

Before transfer, calculate the compressed bundle total, the extracted extension size, installer scratch, image-store growth, the configured OSD image size, and operational headroom. Then check the backing filesystems:

df -hT / /tmp /var/tmp /var/lib /opt
findmnt -T /tmp
findmnt -T /var/tmp
findmnt -T /var/lib
findmnt -T /opt
lsblk -f

There is no release-independent free-space floor for this path. The verified staging copy, /opt/kamiwaza/prereqs copy, logical-wrap scratch space under /var/tmp, extracted extension tree, image store, and configured OSD can coexist. Calculate their peak sizes from the selected handoff and budget each copy on its actual backing filesystem. Grow the correct PV/LV/filesystem before installation and run df again afterward.

Also confirm that no package manager, previous installer, Kubernetes bootstrap, or local-registry import is running. Understand any existing /opt/kamiwaza, /var/lib/k0s, Podman, or cluster state before rerunning an installer.

Verify the host before transferring large artifacts:

(
set -euo pipefail
test "$(uname -m)" = x86_64
grep -E 'release 9([. ]|$)' /etc/redhat-release
test "$(hostnamectl --static | wc -c)" -le 55
((BASH_VERSINFO[0] > 4 ||
  (BASH_VERSINFO[0] == 4 && BASH_VERSINFO[1] >= 4)))
for command_name in \
  awk curl find findmnt gpg jq lsblk rpm sha256sum sort stat sudo systemctl \
  systemd-run tar; do
  command -v "${command_name}" >/dev/null
done
)

If the host is reached through SSM, validate all four access paths before the install window: the instance is Online, a harmless Run Command succeeds, an interactive Session Manager shell opens, and local port forwarding starts. Resolve any configured Session Manager RunAs user mismatch first; do not enable SSH as an ad hoc fallback.

aws ssm describe-instance-information \
  --filters Key=InstanceIds,Values=<instance-id> \
  --region <region> --profile <profile>

COMMAND_ID="$(aws ssm send-command \
  --instance-ids <instance-id> \
  --document-name AWS-RunShellScript \
  --parameters 'commands=["id","true"]' \
  --query 'Command.CommandId' --output text \
  --region <region> --profile <profile>)"
aws ssm wait command-executed \
  --command-id "${COMMAND_ID}" --instance-id <instance-id> \
  --region <region> --profile <profile>
aws ssm get-command-invocation \
  --command-id "${COMMAND_ID}" --instance-id <instance-id> \
  --query '{Status:Status,ResponseCode:ResponseCode}' \
  --region <region> --profile <profile>

aws ssm start-session \
  --target <instance-id> \
  --region <region> --profile <profile>

aws ssm start-session \
  --target <instance-id> \
  --document-name AWS-StartPortForwardingSession \
  --parameters '{"portNumber":["443"],"localPortNumber":["8443"]}' \
  --region <region> --profile <profile>

1. Select and record the exact bundle​

Never copy artifact names, tags, or image overrides from another release. Start with the Keygen release or exact Kajiya workflow run selected for this install and record:

  • release/run identifier, attempt, source prefix, and publication inventory;
  • immutable Kajiya, Deploy, Core, Containers, and extension source commits;
  • every object name and SHA-256, plus sizes where the publisher exposes them;
  • runtime, resource profile, OSD size, and compatibility flags;
  • every product tag and the complete KAMIWAZA_IMAGE_OVERRIDES map;
  • extension helper names and hashes; and
  • the release's required verification gates.

Download release_origination.md first. Its ## Artifacts section is the authoritative hash list for source artifacts and its repository section records provenance. It is not by itself the full launcher contract: settings such as the complete image-override map can come from the exact Kajiya run. If the publisher cannot supply both provenance and the complete install contract, stop instead of guessing from a previous release.

Modern bundle roles normally include:

  • release_origination.md;
  • one kamiwaza-prod-*.el9.x86_64.rpm;
  • one or more kamiwaza-helm.<number>.tar wrap chunks;
  • kamiwaza-helm.sha256, kamiwaza-helm.asc, and the signing public key;
  • optionally, one extension bundle plus its .sha256; and
  • for files split by the distribution service, .part-NNN files, per-part sidecars, and a .parts.json assembly manifest.

The number and names are release-specific. The publisher must supply a complete post-distribution artifacts.tsv with tab-separated filename and SHA-256 columns, including any generated part manifests, parts, and part sidecars. The customer-reachable release_origination.md authenticates source-artifact hashes, but does not enumerate every distribution-added object or provide a byte count for every artifact. If the publisher does not supply the complete post-distribution inventory, stop. Keep it with the installation record.

2. Download, transfer, and verify artifacts​

On the connected staging machine, use the selected package URL and the exact inventory. The example below is deliberately parameterized; <release> is the immutable selected release or run tag, not a version copied from this page.

export RELEASE="<release>"
export PACKAGE_KEY="<exact-package-key-from-the-selected-release>"
export BASE="https://raw.pkg.keygen.sh/kamiwaza/kamiwaza-prod/@${PACKAGE_KEY}/${RELEASE}"
export ARTIFACT_DIR="${PWD}/kamiwaza-offline-${RELEASE}"
export INVENTORY_SOURCE="<secure-path-to-artifacts.tsv>"

(
set -euo pipefail
[[ "${RELEASE}" =~ ^[A-Za-z0-9._-]+$ ]]
[[ "${INVENTORY_SOURCE}" != *'<'* ]]
test -f "${INVENTORY_SOURCE}"

read -rsp 'Kamiwaza license token: ' KEYGEN_TOKEN; printf '\n'

AUTH_HEADER="$(mktemp)"
chmod 0600 "${AUTH_HEADER}"
trap 'rm -f "${AUTH_HEADER}"' EXIT
printf 'Authorization: License %s\n' "${KEYGEN_TOKEN}" >"${AUTH_HEADER}"
unset KEYGEN_TOKEN

install -d -m 0755 "${ARTIFACT_DIR}"
cp "${INVENTORY_SOURCE}" "${ARTIFACT_DIR}/artifacts.tsv"
cd "${ARTIFACT_DIR}"

artifact_count=0
while IFS=$'\t' read -r file expected_sha extra || [[ -n "${file}" ]]; do
  [[ -n "${file}" && "${file}" != \#* ]] || continue
  [[ -z "${extra:-}" ]]
  [[ "${file}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
  [[ "${expected_sha}" =~ ^[0-9a-fA-F]{64}$ ]]
  ((artifact_count += 1))

  if [[ -f "${file}" ]] &&
     printf '%s  %s\n' "${expected_sha}" "${file}" | sha256sum -c - >/dev/null; then
    printf 'already verified: %s\n' "${file}"
    continue
  fi
  rm -f "${file}"

  if [[ -f "${file}.partial" ]] &&
     printf '%s  %s\n' "${expected_sha}" "${file}.partial" | sha256sum -c - >/dev/null; then
    mv "${file}.partial" "${file}"
    continue
  fi

  curl_rc=0
  curl -fL --retry 5 --retry-delay 10 --retry-all-errors --continue-at - \
    --header "@${AUTH_HEADER}" \
    -o "${file}.partial" \
    "${BASE}/${file}" || curl_rc=$?
  if ((curl_rc != 0)); then
    # A rejected/invalid range cannot become resumable without discarding it.
    # Preserve partial bytes for ordinary transport timeouts.
    case "${curl_rc}" in
      22|33|36) rm -f "${file}.partial" ;;
    esac
    exit "${curl_rc}"
  fi

  if ! printf '%s  %s\n' "${expected_sha}" "${file}.partial" | sha256sum -c -; then
    rm -f "${file}.partial"
    printf 'download verification failed: %s\n' "${file}" >&2
    exit 1
  fi
  mv "${file}.partial" "${file}"
done < artifacts.tsv
((artifact_count > 0)) || {
  printf 'artifacts.tsv contained no artifact records\n' >&2
  exit 1
}
)

Do not put license tokens in command logs, shell history, or the installation record. A cloud-to-cloud relay may be faster than a local upload, but use a managed identity or short-lived prefix-scoped credential and verify again on the final target. S3 ETags are not SHA-256 integrity checks.

Reassemble distribution parts​

Each .parts.json records the original filename/hash and the ordered part inventory. Reassemble from that manifest instead of hardcoding part counts:

Skip this block when the inventory contains no .parts.json files.

(
set -euo pipefail
cd "${ARTIFACT_DIR:?export ARTIFACT_DIR first}"
shopt -s nullglob
manifests=( *.parts.json )
((${#manifests[@]} > 0)) || {
  printf 'no part manifests found\n' >&2
  exit 1
}

for manifest in "${manifests[@]}"; do
  output="$(jq -er '.source.filename' "${manifest}")"
  expected_size="$(jq -er '.source.size' "${manifest}")"
  expected_sha="$(jq -er '.source.sha256' "${manifest}")"
  [[ "${output}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
  [[ "${expected_size}" =~ ^[0-9]+$ ]]
  [[ "${expected_sha}" =~ ^[0-9a-fA-F]{64}$ ]]
  jq -e '.parts | type == "array" and length > 0' "${manifest}" >/dev/null

  : > "${output}.assembling"
  part_count=0
  while IFS=$'\t' read -r part part_sha; do
    [[ "${part}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
    [[ "${part_sha}" =~ ^[0-9a-fA-F]{64}$ ]]
    printf '%s  %s\n' "${part_sha}" "${part}" | sha256sum -c -
    cat "${part}" >> "${output}.assembling"
    ((part_count += 1))
  done < <(jq -r '.parts[] | [.filename, .sha256] | @tsv' "${manifest}")

  ((part_count > 0))
  test "$(stat -c %s "${output}.assembling")" = "${expected_size}"
  printf '%s  %s\n' "${expected_sha}" "${output}.assembling" | sha256sum -c -
  mv "${output}.assembling" "${output}"
done
)

Verify source artifacts and the logical wrap​

Verify every artifact recorded in release_origination.md:

(
set -euo pipefail
cd "${ARTIFACT_DIR:?export ARTIFACT_DIR first}"
artifact_count=0
while read -r file expected; do
  test -f "${file}"
  printf '%s  %s\n' "${expected}" "${file}" | sha256sum -c -
  ((artifact_count += 1))
done < <(
  awk '
    $0 == "## Artifacts" { in_artifacts=1; next }
    in_artifacts && /^## / { exit }
    in_artifacts && /^- / {
      name=$2; sub(/:$/, "", name); print name, $3
    }
  ' release_origination.md
)
((artifact_count > 0)) || {
  printf 'release_origination.md contained no artifact records\n' >&2
  exit 1
}
)

kamiwaza-helm.sha256 names the logical concatenated wrap, which might not exist as a physical file. Hash the bytewise concatenation of all numbered wrap chunks in natural numeric order. Creating a similarly named symlink does not verify this contract.

(
set -euo pipefail
cd "${ARTIFACT_DIR:?export ARTIFACT_DIR first}"
mapfile -d '' WRAP_CHUNKS < <(
  find . -maxdepth 1 -type f -regextype posix-extended \
    -regex './kamiwaza-helm\.[0-9]+\.tar' -print0 | sort -z -V
)
((${#WRAP_CHUNKS[@]} > 0))

expected="$(awk 'NR==1 {print $1}' kamiwaza-helm.sha256)"
actual="$(cat "${WRAP_CHUNKS[@]}" | sha256sum | awk '{print $1}')"
test "${actual}" = "${expected}"
printf 'logical wrap checksum: OK (%s chunks)\n' "${#WRAP_CHUNKS[@]}"
)

Verify the detached signature over the checksum file. Confirm the signer fingerprint through an independent trusted channel; a key delivered in the same directory proves bundle consistency, not independently anchored provenance.

(
set -euo pipefail
cd "${ARTIFACT_DIR:?export ARTIFACT_DIR first}"
export GNUPGHOME="$(mktemp -d)"
chmod 0700 "${GNUPGHOME}"
trap 'rm -rf "${GNUPGHOME}"' EXIT
gpg --batch --import ./kamiwaza-tools-rpm.pub.gpg
gpg --batch --verify ./kamiwaza-helm.asc ./kamiwaza-helm.sha256
gpg --batch --with-colons --fingerprint
)

Transfer the entire verified directory to /var/tmp/kamiwaza-offline/<release-or-run> on the target, then repeat the hash, logical-wrap, and signature checks there. Perform the rest of this guide only from that final target copy.

3. Install and verify embedded prerequisites​

Move the verified artifacts into the fixed prerequisite path, install the exact RPM, and run its packaged bootstrap noninteractively:

export ARTIFACT_DIR="/var/tmp/kamiwaza-offline/<release-or-run>"

(
set -euo pipefail

mapfile -t RPM_FILES < <(
  find "${ARTIFACT_DIR}" -maxdepth 1 -type f \
    -name 'kamiwaza-prod-*.el9.x86_64.rpm' -print
)
mapfile -t WRAP_FILES < <(
  find "${ARTIFACT_DIR}" -maxdepth 1 -type f -regextype posix-extended \
    -regex '.*/kamiwaza-helm\.[0-9]+\.tar' -print | sort -V
)
test "${#RPM_FILES[@]}" -eq 1
((${#WRAP_FILES[@]} > 0))

sudo install -d -m 0755 /opt/kamiwaza/prereqs
existing_bundle_file="$({
  sudo find /opt/kamiwaza/prereqs -maxdepth 1 -type f \
    \( -name 'kamiwaza-prod-*.el9.x86_64.rpm' \
       -o -name 'kamiwaza-helm.*.tar' \
       -o -name 'kamiwaza-helm.sha256' \
       -o -name 'kamiwaza-helm.asc' \
       -o -name 'kamiwaza-tools-rpm.pub.gpg' \
       -o -name '*.parts.json' \
       -o -name 'artifacts.tsv' \) \
    -print -quit
})"
if [[ -n "${existing_bundle_file}" ]]; then
  printf 'existing staged bundle artifact: %s\n' "${existing_bundle_file}" >&2
  printf 'verify and archive or remove the complete staged set before retrying, even for the same release\n' >&2
  exit 1
fi

sudo install -o root -g root -m 0600 "${ARTIFACT_DIR}/artifacts.tsv" \
  /opt/kamiwaza/prereqs/artifacts.tsv

declare -A INVENTORY=()
while IFS=$'\t' read -r file expected_sha extra || [[ -n "${file}" ]]; do
  [[ -n "${file}" && "${file}" != \#* ]] || continue
  [[ -z "${extra:-}" ]]
  [[ "${file}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
  [[ "${expected_sha}" =~ ^[0-9a-fA-F]{64}$ ]]
  [[ ! -v "INVENTORY[${file}]" ]]
  INVENTORY["${file}"]="${expected_sha}"
done < <(sudo cat /opt/kamiwaza/prereqs/artifacts.tsv)
((${#INVENTORY[@]} > 0))

# A split source is reconstructed locally and therefore is not itself a row in
# the post-distribution inventory. Root-stage each authenticated manifest and
# add its source hash to the accepted source map.
declare -A SOURCE_INVENTORY=()
shopt -s nullglob
PART_MANIFESTS=("${ARTIFACT_DIR}"/*.parts.json)
for manifest in "${PART_MANIFESTS[@]}"; do
  manifest_name="$(basename "${manifest}")"
  [[ -v "INVENTORY[${manifest_name}]" ]]
  sudo cp "${manifest}" /opt/kamiwaza/prereqs/
  printf '%s  %s\n' "${INVENTORY[${manifest_name}]}" \
    "/opt/kamiwaza/prereqs/${manifest_name}" | sudo sha256sum -c -
  source_name="$(sudo jq -er '.source.filename' \
    "/opt/kamiwaza/prereqs/${manifest_name}")"
  source_sha="$(sudo jq -er '.source.sha256' \
    "/opt/kamiwaza/prereqs/${manifest_name}")"
  [[ "${source_name}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
  [[ "${source_sha}" =~ ^[0-9a-fA-F]{64}$ ]]
  [[ ! -v "SOURCE_INVENTORY[${source_name}]" ]]
  SOURCE_INVENTORY["${source_name}"]="${source_sha}"
done

sudo cp "${RPM_FILES[@]}" \
  "${WRAP_FILES[@]}" \
  "${ARTIFACT_DIR}"/kamiwaza-helm.sha256 \
  "${ARTIFACT_DIR}"/kamiwaza-helm.asc \
  "${ARTIFACT_DIR}"/kamiwaza-tools-rpm.pub.gpg \
  /opt/kamiwaza/prereqs/

STAGED_FILES=(
  "${RPM_FILES[@]}"
  "${WRAP_FILES[@]}"
  "${ARTIFACT_DIR}/kamiwaza-helm.sha256"
  "${ARTIFACT_DIR}/kamiwaza-helm.asc"
  "${ARTIFACT_DIR}/kamiwaza-tools-rpm.pub.gpg"
)
for source in "${STAGED_FILES[@]}"; do
  name="$(basename "${source}")"
  if [[ -v "INVENTORY[${name}]" ]]; then
    expected_sha="${INVENTORY[${name}]}"
  else
    [[ -v "SOURCE_INVENTORY[${name}]" ]]
    expected_sha="${SOURCE_INVENTORY[${name}]}"
  fi
  printf '%s  %s\n' "${expected_sha}" \
    "/opt/kamiwaza/prereqs/${name}" | sudo sha256sum -c -
done

RPM_NAME="$(basename "${RPM_FILES[0]}")"
sudo rpm -Uvh --replacepkgs "/opt/kamiwaza/prereqs/${RPM_NAME}"
sudo /opt/kamiwaza/scripts/bootstrap-prereqs.sh \
  --yes \
  --embedded-root /opt/kamiwaza/prereqs \
  --os rhel
)

The release/1.2.0 RPM overlay accepts --yes for noninteractive bootstrap. Do not pipe repeated yes or press Enter to drive a long unattended install.

The install runs as root, so verify tools using root's actual environment:

(
set -euo pipefail
sudo env \
  HOME=/root \
  PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin \
  HELM_PLUGINS=/usr/local/share/helm/plugins \
  bash -euo pipefail -c '
    ansible-playbook --version | head -n1
    podman --version
    kubectl version --client
    helm version --short
    helmfile --version
    helm dt version
  '
)

Do not repair a missing embedded tool by silently installing an arbitrary internet version. Reconcile the selected RPM/bootstrap contract first.

4. Pre-stage the extension bundle (optional)​

Skip this section when the selected bundle has no extension archive. Pre-stage loads the bundled catalog files and writes offline catalog values needed by the core install. It does not load all images or import the live catalog.

Copy the verified extension archive and sidecar into /opt/kamiwaza/prereqs. Derive and validate its single top-level directory, then record the exact final bundle root. Do not rediscover it later with find | head; stale extractions can coexist after a retry.

export RUN_ID="<release-or-run>"
export EXT_BUNDLE="<exact-extension-filename-from-inventory>"
export EXTRACT_DIR="/var/lib/kajiya-reports/extensions-${RUN_ID}"
export ROOT_RECORD="/var/lib/kajiya-reports/offline-install/${RUN_ID}/bundle-root"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${EXT_BUNDLE}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
HELPER_DIR="$(sudo mktemp -d -p /var/tmp \
  "kamiwaza-extension-helper-${RUN_ID}.XXXXXX")"
trap 'sudo rm -rf -- "${HELPER_DIR}"' EXIT

sudo cp "${ARTIFACT_DIR}/${EXT_BUNDLE}" \
  "${ARTIFACT_DIR}/${EXT_BUNDLE}.sha256" \
  /opt/kamiwaza/prereqs/

for name in "${EXT_BUNDLE}" "${EXT_BUNDLE}.sha256"; do
  mapfile -t expected_rows < <(
    sudo awk -F '\t' -v name="${name}" '$1 == name {print $2}' \
      /opt/kamiwaza/prereqs/artifacts.tsv
  )
  if ((${#expected_rows[@]} == 0)); then
    mapfile -t root_manifests < <(
      sudo find /opt/kamiwaza/prereqs -maxdepth 1 -type f \
        -name '*.parts.json' -print
    )
    for manifest in "${root_manifests[@]}"; do
      if [[ "$(sudo jq -er '.source.filename' "${manifest}")" = "${name}" ]]; then
        expected_rows+=("$(sudo jq -er '.source.sha256' "${manifest}")")
      fi
    done
  fi
  test "${#expected_rows[@]}" -eq 1
  [[ "${expected_rows[0]}" =~ ^[0-9a-fA-F]{64}$ ]]
  printf '%s  %s\n' "${expected_rows[0]}" \
    "/opt/kamiwaza/prereqs/${name}" | sudo sha256sum -c -
done

mapfile -t BUNDLE_TOP_LEVELS < <(
  sudo tar -tzf "/opt/kamiwaza/prereqs/${EXT_BUNDLE}" |
    awk -F/ 'NF {print $1}' | sort -u
)
test "${#BUNDLE_TOP_LEVELS[@]}" -eq 1
export BUNDLE_DIR_NAME="${BUNDLE_TOP_LEVELS[0]}"
[[ "${BUNDLE_DIR_NAME}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]

sudo tar -xzf "/opt/kamiwaza/prereqs/${EXT_BUNDLE}" -C "${HELPER_DIR}" -- \
  "${BUNDLE_DIR_NAME}/scripts/install-extensions-bundle.sh"
sudo test -x \
  "${HELPER_DIR}/${BUNDLE_DIR_NAME}/scripts/install-extensions-bundle.sh"
sudo bash "${HELPER_DIR}/${BUNDLE_DIR_NAME}/scripts/install-extensions-bundle.sh" \
  --bundle "/opt/kamiwaza/prereqs/${EXT_BUNDLE}" \
  --sha256-file "/opt/kamiwaza/prereqs/${EXT_BUNDLE}.sha256" \
  --extract-dir "${EXTRACT_DIR}" \
  --skip-images \
  --skip-catalog

export BUNDLE_ROOT="${EXTRACT_DIR}/${BUNDLE_DIR_NAME}"
sudo test -x "${BUNDLE_ROOT}/scripts/install-extensions-bundle.sh"
sudo install -d -m 0700 "$(dirname "${ROOT_RECORD}")"
printf '%s\n' "${BUNDLE_ROOT}" | sudo tee "${ROOT_RECORD}" >/dev/null
sudo chmod 0600 "${ROOT_RECORD}"
)

When helpers are supplied separately from the archive, use only the exact Kajiya commit recorded by the selected run and verify each helper SHA-256 before execution.

5. Prepare a durable core launcher​

The selected immutable run must supply a complete, non-secret install contract. Record it as JSON so values containing spaces cannot become shell syntax. Fill every value from the selected run, including the complete infrastructure and inference image map:

{
  "KAMIWAZA_VERSION": "<exact>",
  "KAMIWAZA_IMAGE_TAG": "<exact>",
  "KAMIWAZA_K8S_RUNTIME": "k0s-podman",
  "KAMIWAZA_ROOK_OSD_IMAGE_SIZE": "<exact>",
  "KAMIWAZA_RESOURCE_PROFILE": "<exact>",
  "HELMFILE_EXTRA_SET": "<exact, including spaces>",
  "KAMIWAZA_OFFLINE_APP_IMAGE_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_CURL_SHELL_IMAGE_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_CORE_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_DATAHUB_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_FRONTEND_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_INIT_KEYCLOAK_USERS_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_CONTAINERS_IMAGE_TAG": "<exact>",
  "KAMIWAZA_OFFLINE_CHAINGUARD_BASE_TAG": "<exact>",
  "KAMIWAZA_IMAGE_OVERRIDES": "<exact comma-separated map>"
}

Validate that the document contains only the expected string keys, then install it root-owned:

(
set -euo pipefail
CONTRACT_SOURCE='<secure-path-to-kamiwaza-install-contract.json>'
[[ "${CONTRACT_SOURCE}" != *'<'* ]]
test -f "${CONTRACT_SOURCE}"
if ! jq -e '
  type == "object" and
  (keys | sort) == ([
    "HELMFILE_EXTRA_SET",
    "KAMIWAZA_IMAGE_OVERRIDES",
    "KAMIWAZA_IMAGE_TAG",
    "KAMIWAZA_K8S_RUNTIME",
    "KAMIWAZA_OFFLINE_APP_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_CHAINGUARD_BASE_TAG",
    "KAMIWAZA_OFFLINE_CONTAINERS_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_CORE_TAG",
    "KAMIWAZA_OFFLINE_CURL_SHELL_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_DATAHUB_TAG",
    "KAMIWAZA_OFFLINE_FRONTEND_TAG",
    "KAMIWAZA_OFFLINE_INIT_KEYCLOAK_USERS_TAG",
    "KAMIWAZA_RESOURCE_PROFILE",
    "KAMIWAZA_ROOK_OSD_IMAGE_SIZE",
    "KAMIWAZA_VERSION"
  ] | sort) and
  all(.[]; type == "string") and
  all(.[]; (contains("<") or contains(">")) | not) and
  .KAMIWAZA_K8S_RUNTIME == "k0s-podman" and
  (. as $contract | all([
    "KAMIWAZA_IMAGE_OVERRIDES",
    "KAMIWAZA_IMAGE_TAG",
    "KAMIWAZA_K8S_RUNTIME",
    "KAMIWAZA_OFFLINE_APP_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_CHAINGUARD_BASE_TAG",
    "KAMIWAZA_OFFLINE_CONTAINERS_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_CORE_TAG",
    "KAMIWAZA_OFFLINE_CURL_SHELL_IMAGE_TAG",
    "KAMIWAZA_OFFLINE_DATAHUB_TAG",
    "KAMIWAZA_OFFLINE_FRONTEND_TAG",
    "KAMIWAZA_OFFLINE_INIT_KEYCLOAK_USERS_TAG",
    "KAMIWAZA_RESOURCE_PROFILE",
    "KAMIWAZA_ROOK_OSD_IMAGE_SIZE",
    "KAMIWAZA_VERSION"
  ][]; ($contract[.] | length > 0)))
' "${CONTRACT_SOURCE}" >/dev/null; then
  printf 'install contract has missing, extra, empty, placeholder, or topology-invalid values\n' >&2
  exit 1
fi
sudo install -o root -g root -m 0600 \
  "${CONTRACT_SOURCE}" /run/kamiwaza-install-contract.json
)

Use the exact release contract even when several values happen to share a tag. Do not synthesize missing values from the release number. KAMIWAZA_K8S_RUNTIME must be k0s-podman for this guide. If the selected contract names another runtime, stop and use that runtime's runbook. KAMIWAZA_OFFLINE_EXTRA_IMAGES is a Kajiya wrap-build input, not an installer environment variable; record it in build provenance when it is nonempty, but do not add it to this runtime contract.

Upgrading a 1.0.0 production database to 1.2.0? Stop here and follow the Core database upgrade runbook before invoking install-prod.sh. It requires the exact 1.2.0 candidate, a pre-mutation backup, schema gates, stop rules, and recovery evidence.

Password handling​

The packaged release/1.2.0 RPM passes unknown arguments through to Ansible. The launcher below writes admin_password to a root-only, attempt-bound JSON extra-vars file under /run and passes only that file's path. The password is not placed in the installer or child-process arguments or environment. Root can still read the temporary file while the phase is running; the launcher's exit trap removes it.

Read the password without echoing it and create a transient root-only file:

(
set -euo pipefail
read -rsp 'Initial Kamiwaza admin password: ' ADMIN_PASSWORD; printf '\n'
sudo install -o root -g root -m 0600 /dev/null /run/kamiwaza-admin-password
printf '%s' "${ADMIN_PASSWORD}" | sudo tee /run/kamiwaza-admin-password >/dev/null
unset ADMIN_PASSWORD
)

Create /run/kamiwaza-offline-install.sh as root with a quoted heredoc so the interactive shell cannot expand the script body:

(
set -euo pipefail
sudo install -o root -g root -m 0700 /dev/null \
  /run/kamiwaza-offline-install.sh
sudo tee /run/kamiwaza-offline-install.sh >/dev/null <<'KAMIWAZA_INSTALL'
#!/usr/bin/env bash
set -euo pipefail

export HOME=/root
export PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
export HELM_PLUGINS=/usr/local/share/helm/plugins
export KUBECONFIG=/var/lib/k0s/pki/admin.conf
unset NAMESPACE

CONTRACT=/run/kamiwaza-install-contract.json
PASSWORD_FILE=/run/kamiwaza-admin-password
DOMAIN='<domain>'
RUN_ID="${1:?pass the recorded run ID}"
ATTEMPT_ID="${2:?pass the recorded attempt number}"
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${ATTEMPT_ID}" =~ ^[0-9]+$ ]]
STATUS_ROOT="/var/lib/kajiya-reports/offline-install/${RUN_ID}/core-attempts"
ATTEMPT_DIR="${STATUS_ROOT}/attempt${ATTEMPT_ID}"
STATUS_FILE="${ATTEMPT_DIR}/result.rc"
ADMIN_VARS_FILE="/run/kamiwaza-admin-extra-vars-${RUN_ID}-attempt${ATTEMPT_ID}.json"

test -d "${ATTEMPT_DIR}"
test ! -e "${STATUS_FILE}"
test ! -e "${ADMIN_VARS_FILE}"
umask 077
cat /proc/sys/kernel/random/boot_id >"${ATTEMPT_DIR}/boot-id"
exec >"${ATTEMPT_DIR}/console.log" 2>&1

finish() {
  rc=$?
  trap - EXIT
  rm -f "${PASSWORD_FILE}" "${ADMIN_VARS_FILE}"
  status_tmp="$(mktemp "${STATUS_FILE}.tmp.XXXXXX")"
  printf '%s\n' "${rc}" >"${status_tmp}"
  chmod 0600 "${status_tmp}"
  mv -f "${status_tmp}" "${STATUS_FILE}"
  exit "${rc}"
}
trap finish EXIT
trap 'exit 129' HUP
trap 'exit 130' INT
trap 'exit 143' TERM

[[ -n "${DOMAIN}" && "${DOMAIN}" != *'<'* ]]
test -s "${CONTRACT}"
test -s "${PASSWORD_FILE}"
test -f /opt/kamiwaza/prereqs/kamiwaza-helm.sha256
test -f /opt/kamiwaza/prereqs/kamiwaza-helm.asc
test -f /opt/kamiwaza/prereqs/kamiwaza-tools-rpm.pub.gpg

CONTRACT_KEYS=(
  KAMIWAZA_VERSION
  KAMIWAZA_IMAGE_TAG
  KAMIWAZA_K8S_RUNTIME
  KAMIWAZA_ROOK_OSD_IMAGE_SIZE
  KAMIWAZA_RESOURCE_PROFILE
  HELMFILE_EXTRA_SET
  KAMIWAZA_OFFLINE_APP_IMAGE_TAG
  KAMIWAZA_OFFLINE_CURL_SHELL_IMAGE_TAG
  KAMIWAZA_OFFLINE_CORE_TAG
  KAMIWAZA_OFFLINE_DATAHUB_TAG
  KAMIWAZA_OFFLINE_FRONTEND_TAG
  KAMIWAZA_OFFLINE_INIT_KEYCLOAK_USERS_TAG
  KAMIWAZA_OFFLINE_CONTAINERS_IMAGE_TAG
  KAMIWAZA_OFFLINE_CHAINGUARD_BASE_TAG
  KAMIWAZA_IMAGE_OVERRIDES
)
for name in "${CONTRACT_KEYS[@]}"; do
  value="$(jq -er --arg name "${name}" '.[$name] | strings' "${CONTRACT}")"
  printf -v "${name}" '%s' "${value}"
  export "${name}"
done
unset value

jq -Rs '{admin_password: .}' <"${PASSWORD_FILE}" >"${ADMIN_VARS_FILE}"
test -s "${ADMIN_VARS_FILE}"
rm -f "${PASSWORD_FILE}"
/opt/kamiwaza/scripts/install-prod.sh \
  --offline \
  --skip-prereq-bootstrap \
  --domain "${DOMAIN}" \
  --wrap-bundle '/opt/kamiwaza/prereqs/kamiwaza-helm.*.tar' \
  --wrap-sha256 /opt/kamiwaza/prereqs/kamiwaza-helm.sha256 \
  --wrap-signature /opt/kamiwaza/prereqs/kamiwaza-helm.asc \
  --wrap-pubkey /opt/kamiwaza/prereqs/kamiwaza-tools-rpm.pub.gpg \
  --extra-vars "@${ADMIN_VARS_FILE}" \
  -y
KAMIWAZA_INSTALL
)

Replace <domain> with sudoedit /run/kamiwaza-offline-install.sh, then validate and protect the launcher:

(
set -euo pipefail
sudo bash -n /run/kamiwaza-offline-install.sh
sudo chmod 0700 /run/kamiwaza-offline-install.sh
)

6. Launch through SSM without tying the install to the shell​

An SSM interactive shell can time out while a healthy installation is still running. Launch each attempt as a distinct transient systemd unit:

export RUN_ID="<release-or-run>"
export ATTEMPT=1
export CORE_UNIT="kamiwaza-offline-install-${RUN_ID}-attempt${ATTEMPT}.service"
export CORE_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/core-attempts/attempt${ATTEMPT}"
export CORE_STATUS="${CORE_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${ATTEMPT}" =~ ^[0-9]+$ ]]
sudo install -d -o root -g root -m 0700 "$(dirname "${CORE_ATTEMPT_DIR}")"
sudo mkdir -m 0700 "${CORE_ATTEMPT_DIR}"
sudo systemd-run \
  --no-block \
  --service-type=oneshot \
  --remain-after-exit \
  --unit="${CORE_UNIT%.service}" \
  --property=KillMode=process \
  --property=Delegate=yes \
  --property=TimeoutStartSec=infinity \
  /bin/bash /run/kamiwaza-offline-install.sh "${RUN_ID}" "${ATTEMPT}"
printf 'record unit=%s attempt_dir=%s\n' "${CORE_UNIT}" "${CORE_ATTEMPT_DIR}"
)

Immediately record the unit name and follow the persistent root-only log:

sudo tail -F "${CORE_ATTEMPT_DIR}/console.log"

Stop following with Ctrl-C only after the unit is terminal; then run the strict completion gate in the next section.

Journal activity—or quietness—is not a completion signal. Because KillMode=process and Delegate=yes allow runtime children to survive the launcher, a stopped unit also does not prove all children stopped after an error. Declare the core launcher successful only when all of these agree:

  • LoadState=loaded, ActiveState=active, SubState=exited, Result=success, ExecMainCode=1, and ExecMainStatus=0 from one systemctl show snapshot;
  • the recorded per-attempt ${CORE_STATUS} contains 0;
  • the final Ansible recap has failed=0 and unreachable=0; and
  • the independent workload checks in the next section pass.

--remain-after-exit keeps a successful transient unit loaded so a misspelled, garbage-collected, or never-created unit cannot look identical to success. systemd-run is preferred on RHEL because it preserves an authoritative exit status. If systemd transient units are unavailable, the launcher can be detached with nohup and the same attempt argument:

export ATTEMPT=2
export CORE_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/core-attempts/attempt${ATTEMPT}"
export CORE_STATUS="${CORE_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${ATTEMPT}" =~ ^[0-9]+$ ]]
sudo install -d -o root -g root -m 0700 "$(dirname "${CORE_ATTEMPT_DIR}")"
sudo mkdir -m 0700 "${CORE_ATTEMPT_DIR}"
sudo /bin/bash -c '
  exec nohup /bin/bash "$1" "$2" "$3" </dev/null >"$4" 2>&1 &
' _ /run/kamiwaza-offline-install.sh "${RUN_ID}" "${ATTEMPT}" \
  "${CORE_ATTEMPT_DIR}/launcher.log"
)

In that fallback, require the runner's .rc file plus the final recap and all independent health gates; the background PID disappearing is not success.

7. Verify the core installation​

The k0s-podman topology uses Podman as the k0s container engine on the host:

RHEL host -> k0s with Podman container engine -> Kubernetes pods

Host processes and Kubernetes workloads do not share one network namespace. Use the root kubeconfig installed by the playbook and the node IP reported by Kubernetes. If an EC2 instance role is intentionally available to workloads, the instance metadata response hop limit must support this nested path; explicit S3 credentials remain supported when ambient identity is not desired.

For a same-boot verification, rebind the recorded values after reconnecting and run:

export DOMAIN="<domain>"
export RUN_ID="<release-or-run>"
export ATTEMPT=1
export CORE_UNIT="kamiwaza-offline-install-${RUN_ID}-attempt${ATTEMPT}.service"
export CORE_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/core-attempts/attempt${ATTEMPT}"
export CORE_STATUS="${CORE_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
test "$(sudo cat "${CORE_ATTEMPT_DIR}/boot-id")" = \
  "$(cat /proc/sys/kernel/random/boot_id)"
CORE_STATE="$(sudo systemctl show "${CORE_UNIT}" \
  -p LoadState -p ActiveState -p SubState -p Result \
  -p ExecMainCode -p ExecMainStatus -p InvocationID)"
printf '%s\n' "${CORE_STATE}"
for expected in \
  LoadState=loaded ActiveState=active SubState=exited \
  Result=success ExecMainCode=1 ExecMainStatus=0; do
  if ! grep -Fxq "${expected}" <<<"${CORE_STATE}"; then
    printf 'core unit state gate failed: missing %s\n' "${expected}" >&2
    exit 1
  fi
done
grep -Eq '^InvocationID=.+$' <<<"${CORE_STATE}"
test "$(sudo cat "${CORE_STATUS}")" = 0
)

Run the workload gates separately so the same block is usable after a verified post-success reboot:

export DOMAIN="<domain>"

(
set -euo pipefail
ROOT_TOOLS=(sudo env \
  PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin \
  HELM_PLUGINS=/usr/local/share/helm/plugins \
  KUBECONFIG=/var/lib/k0s/pki/admin.conf)
NODES_JSON="$("${ROOT_TOOLS[@]}" kubectl get nodes -o json)"
jq -e '
  (.items | length) > 0 and
  all(.items[]; any(.status.conditions[]?;
    .type == "Ready" and .status == "True"))
' <<<"${NODES_JSON}" >/dev/null

PODS_JSON="$("${ROOT_TOOLS[@]}" kubectl get pods -A -o json)"
jq -e '
  (.items | length) > 0 and
  all(.items[];
    .status.phase == "Succeeded" or
    (.status.phase == "Running" and
     ((.status.containerStatuses // []) | length) > 0 and
     all(.status.containerStatuses[]; .ready == true)))
' <<<"${PODS_JSON}" >/dev/null
jq -e '
  all(.items[];
    all((.status.containerStatuses // [])[];
      (.imageID // "") | contains("sha256:")))
' <<<"${PODS_JSON}" >/dev/null

HELM_JSON="$("${ROOT_TOOLS[@]}" helm list -A -o json)"
jq -e 'length > 0 and all(.[]; .status == "deployed")' \
  <<<"${HELM_JSON}" >/dev/null

NODE_IP="$("${ROOT_TOOLS[@]}" kubectl get nodes \
  -o jsonpath='{.items[0].status.addresses[?(@.type=="InternalIP")].address}')"
test -n "${NODE_IP}"
HTTP_CODE="$(curl -kfsS --resolve "${DOMAIN}:443:${NODE_IP}" \
  -o /dev/null -w '%{http_code}' \
  "https://${DOMAIN}/api/auth/health")"
test "${HTTP_CODE}" = 200

"${ROOT_TOOLS[@]}" kubectl get nodes -o wide
"${ROOT_TOOLS[@]}" kubectl get pods -A
"${ROOT_TOOLS[@]}" helm list -A
printf 'health HTTP %s\n' "${HTTP_CODE}"
)

If the host rebooted only after the durable result.rc reached 0, the transient unit tuple is no longer available. Do not run the same-boot tuple gate. Instead require that attempt's root-only console.log to contain the final clean Ansible recap, then run the separate workload block and every login, digest, and provenance gate below. A missing or nonzero receipt is not recoverable success.

The health endpoint is authentication-exempt and must return a successful HTTP status. Also verify login and an authenticated API request, deployed Helm releases, expected local-registry manifests, and the live pod imageID digests against the selected release contract. Health without expected digest evidence proves function, not artifact provenance. Passing the shell block alone is not level-1 completion; login and an authenticated request must also succeed. A missing expected manifest/digest comparison does not block that functional level, but it does block any claim that the running images match the selected release provenance.

The domain must resolve both from the install host and from the operator's browser. Add one exact, reviewed /etc/hosts entry only when DNS is not ready; do not append duplicates on every retry.

For SSM port forwarding, map local port 8443 to target port 443, add 127.0.0.1 <domain> to the operator workstation, and browse to https://<domain>:8443/login. The default certificate is self-signed, so the browser presents a warning until the operator explicitly trusts or replaces it. Preserve :8443 after authentication redirects.

8. Fully load bundled extensions (optional)​

Core success does not finish a bundle that contains extensions. Run the full load in a separate detached unit after the authenticated API is ready. Reuse the exact root recorded during pre-stage; do not extract another copy without a specific reason.

Create /run/kamiwaza-offline-extensions.sh through a root-owned quoted heredoc:

(
set -euo pipefail
sudo install -o root -g root -m 0700 /dev/null \
  /run/kamiwaza-offline-extensions.sh
sudo tee /run/kamiwaza-offline-extensions.sh >/dev/null <<'KAMIWAZA_EXTENSIONS'
#!/usr/bin/env bash
set -euo pipefail

export HOME=/root
export PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
export HELM_PLUGINS=/usr/local/share/helm/plugins
export KUBECONFIG=/var/lib/k0s/pki/admin.conf
unset NAMESPACE

DOMAIN='<domain>'
RUN_ID="${1:?pass the recorded run ID}"
ATTEMPT_ID="${2:?pass the recorded attempt number}"
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${ATTEMPT_ID}" =~ ^[0-9]+$ ]]
ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/extension-attempts/attempt${ATTEMPT_ID}"
STATUS_FILE="${ATTEMPT_DIR}/result.rc"
ROOT_RECORD="/var/lib/kajiya-reports/offline-install/${RUN_ID}/bundle-root"
BUNDLE_ROOT="$(<"${ROOT_RECORD}")"

test -d "${ATTEMPT_DIR}"
test ! -e "${STATUS_FILE}"
umask 077
cat /proc/sys/kernel/random/boot_id >"${ATTEMPT_DIR}/boot-id"
exec >"${ATTEMPT_DIR}/console.log" 2>&1

finish() {
  rc=$?
  trap - EXIT
  status_tmp="$(mktemp "${STATUS_FILE}.tmp.XXXXXX")"
  printf '%s\n' "${rc}" >"${status_tmp}"
  chmod 0600 "${status_tmp}"
  mv -f "${status_tmp}" "${STATUS_FILE}"
  exit "${rc}"
}
trap finish EXIT
trap 'exit 129' HUP
trap 'exit 130' INT
trap 'exit 143' TERM

[[ -n "${DOMAIN}" && "${DOMAIN}" != *'<'* ]]
test -d "${BUNDLE_ROOT}"
test -x "${BUNDLE_ROOT}/scripts/install-extensions-bundle.sh"

# Do not persist the seeded credential in a second file. Feed it to the helper
# on stdin; see the argv limitation immediately below.
ADMIN_PASSWORD="$(
  kubectl -n kamiwaza get secret kamiwaza-user-admin \
    -o jsonpath='{.data.password}' | base64 -d
)"

printf '%s\n' "${ADMIN_PASSWORD}" |
  "${BUNDLE_ROOT}/scripts/install-extensions-bundle.sh" \
    --bundle-root "${BUNDLE_ROOT}" \
    --container-cli podman \
    --sudo-mode always \
    --api-url "https://${DOMAIN}/api" \
    --username admin \
    --password-stdin
unset ADMIN_PASSWORD
KAMIWAZA_EXTENSIONS
)

The current bundle helper accepts --password-stdin, but its catalog-import subprocess can still expand that value into a child command's arguments. This has the same temporary privileged-process visibility limitation as the core installer. Do not capture full process argument lists during this phase.

Launch and monitor it like the core phase:

export RUN_ID="<release-or-run>"
export EXT_ATTEMPT=1
export EXT_UNIT="kamiwaza-offline-extensions-${RUN_ID}-attempt${EXT_ATTEMPT}.service"
export EXT_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/extension-attempts/attempt${EXT_ATTEMPT}"
export EXT_STATUS="${EXT_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${EXT_ATTEMPT}" =~ ^[0-9]+$ ]]
sudo bash -n /run/kamiwaza-offline-extensions.sh
sudo chmod 0700 /run/kamiwaza-offline-extensions.sh
sudo install -d -o root -g root -m 0700 "$(dirname "${EXT_ATTEMPT_DIR}")"
sudo mkdir -m 0700 "${EXT_ATTEMPT_DIR}"
sudo systemd-run \
  --no-block \
  --service-type=oneshot \
  --remain-after-exit \
  --unit="${EXT_UNIT%.service}" \
  --property=KillMode=process \
  --property=Delegate=yes \
  --property=TimeoutStartSec=infinity \
  /bin/bash /run/kamiwaza-offline-extensions.sh "${RUN_ID}" "${EXT_ATTEMPT}"
printf 'record unit=%s attempt_dir=%s\n' "${EXT_UNIT}" "${EXT_ATTEMPT_DIR}"
)

sudo tail -F "${EXT_ATTEMPT_DIR}/console.log"

After the unit is terminal, stop following with Ctrl-C and gate the exact recorded attempt:

export RUN_ID="<release-or-run>"
export EXT_ATTEMPT=1
export EXT_UNIT="kamiwaza-offline-extensions-${RUN_ID}-attempt${EXT_ATTEMPT}.service"
export EXT_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/extension-attempts/attempt${EXT_ATTEMPT}"
export EXT_STATUS="${EXT_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
test "$(sudo cat "${EXT_ATTEMPT_DIR}/boot-id")" = \
  "$(cat /proc/sys/kernel/random/boot_id)"
EXT_STATE="$(sudo systemctl show "${EXT_UNIT}" \
  -p LoadState -p ActiveState -p SubState -p Result \
  -p ExecMainCode -p ExecMainStatus -p InvocationID)"
printf '%s\n' "${EXT_STATE}"
for expected in \
  LoadState=loaded ActiveState=active SubState=exited \
  Result=success ExecMainCode=1 ExecMainStatus=0; do
  if ! grep -Fxq "${expected}" <<<"${EXT_STATE}"; then
    printf 'extension unit state gate failed: missing %s\n' "${expected}" >&2
    exit 1
  fi
done
grep -Eq '^InvocationID=.+$' <<<"${EXT_STATE}"
test "$(sudo cat "${EXT_STATUS}")" = 0
sudo env \
  PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin \
  KUBECONFIG=/var/lib/k0s/pki/admin.conf \
  kubectl get pods -A
)

Also require all expected local-registry manifests and healthy workloads. Record the exact stored and visible catalog counts for the selected immutable bundle. Stored and visible counts can differ when product posture intentionally hides a template; verify both instead of assuming that an absent UI card means import failed.

Customer level-2 completion does not require private Kajiya smoke helpers or unpublished expected-count files. If the publisher supplies an additional hash-authenticated validation pack, run its resource assertions; otherwise record the observed evidence without substituting dated counts from this page.

Do not blindly rerun only the catalog importer after success. Existing hidden templates can be invisible to its list call and then cause a duplicate-create HTTP 400.

9. Run the internal release deploy gate (release parity)​

This section is for Kamiwaza release engineers. The normal customer bundle does not contain smoke-extension-deploy.sh, the Konnectivity guard, or expected release-gate values. Do not require this section for customer level-1 or level-2 completion. For release/nightly parity, transfer the selected run's separate validation pack and verify its recorded hashes; never download develop at install time.

Install the verified gate into a fresh root-only directory:

export RUN_ID="<release-or-run>"
export GATE_SOURCE="<secure-path-to-smoke-extension-deploy.sh>"
export GATE_SHA256="<sha256-from-selected-validation-pack>"
export GATE_HELPER_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/release-validation"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${GATE_SHA256}" =~ ^[0-9a-fA-F]{64}$ ]]
[[ "${GATE_SOURCE}" != *'<'* ]]
test -f "${GATE_SOURCE}"
printf '%s  %s\n' "${GATE_SHA256}" "${GATE_SOURCE}" | sha256sum -c -
sudo install -d -o root -g root -m 0700 "$(dirname "${GATE_HELPER_DIR}")"
sudo mkdir -m 0700 "${GATE_HELPER_DIR}"
sudo install -o root -g root -m 0700 "${GATE_SOURCE}" \
  "${GATE_HELPER_DIR}/smoke-extension-deploy.sh"
printf '%s  %s\n' "${GATE_SHA256}" \
  "${GATE_HELPER_DIR}/smoke-extension-deploy.sh" | sudo sha256sum -c -
)

The currently selected 1.2.0 gate deploys kaizen, but the selected release contract controls the exact template. The gate waits for readiness, proves that relocation left no external image references, and removes it through the supported API path. A raw kubectl apply bypasses that behavior and is not an equivalent test.

Create /run/kamiwaza-offline-extension-gate.sh through a root-owned quoted heredoc, replacing the placeholders with the recorded domain and gate values:

(
set -euo pipefail
sudo install -o root -g root -m 0700 /dev/null \
  /run/kamiwaza-offline-extension-gate.sh
sudo tee /run/kamiwaza-offline-extension-gate.sh >/dev/null <<'KAMIWAZA_GATE'
#!/usr/bin/env bash
set -euo pipefail

export HOME=/root
export PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
export HELM_PLUGINS=/usr/local/share/helm/plugins
export KUBECONFIG=/var/lib/k0s/pki/admin.conf
unset NAMESPACE

DOMAIN='<domain>'
RUN_ID="${1:?pass the recorded run ID}"
ATTEMPT_ID="${2:?pass the recorded attempt number}"
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${ATTEMPT_ID}" =~ ^[0-9]+$ ]]
ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/gate-attempts/attempt${ATTEMPT_ID}"
STATUS_FILE="${ATTEMPT_DIR}/result.rc"
GATE_SCRIPT="/var/lib/kajiya-reports/offline-install/${RUN_ID}/release-validation/smoke-extension-deploy.sh"
GATE_TEMPLATE='<exact-gate-template-from-selected-release>'
GATE_WAIT_TIMEOUT='<exact-gate-timeout-from-selected-release>'

test -d "${ATTEMPT_DIR}"
test ! -e "${STATUS_FILE}"
umask 077
cat /proc/sys/kernel/random/boot_id >"${ATTEMPT_DIR}/boot-id"
exec >"${ATTEMPT_DIR}/console.log" 2>&1

finish() {
  rc=$?
  trap - EXIT
  status_tmp="$(mktemp "${STATUS_FILE}.tmp.XXXXXX")"
  printf '%s\n' "${rc}" >"${status_tmp}"
  chmod 0600 "${status_tmp}"
  mv -f "${status_tmp}" "${STATUS_FILE}"
  exit "${rc}"
}
trap finish EXIT
trap 'exit 129' HUP
trap 'exit 130' INT
trap 'exit 143' TERM

[[ -n "${DOMAIN}" && "${DOMAIN}" != *'<'* ]]
[[ "${GATE_TEMPLATE}" != *'<'* ]]
[[ "${GATE_WAIT_TIMEOUT}" != *'<'* ]]
test -x "${GATE_SCRIPT}"
ADMIN_PASSWORD="$(
  kubectl -n kamiwaza get secret kamiwaza-user-admin \
    -o jsonpath='{.data.password}' | base64 -d
)"

printf '%s\n' "${ADMIN_PASSWORD}" |
  bash "${GATE_SCRIPT}" \
    --api-url "https://${DOMAIN}/api" \
    --username admin \
    --password-stdin \
    --template-name "${GATE_TEMPLATE}" \
    --wait-timeout "${GATE_WAIT_TIMEOUT}"
unset ADMIN_PASSWORD
KAMIWAZA_GATE
)

Launch and gate it independently:

export RUN_ID="<release-or-run>"
export GATE_ATTEMPT=1
export GATE_UNIT="kamiwaza-offline-extension-gate-${RUN_ID}-attempt${GATE_ATTEMPT}.service"
export GATE_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/gate-attempts/attempt${GATE_ATTEMPT}"
export GATE_STATUS="${GATE_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
[[ "${RUN_ID}" =~ ^[A-Za-z0-9][A-Za-z0-9._-]*$ ]]
[[ "${GATE_ATTEMPT}" =~ ^[0-9]+$ ]]
sudo bash -n /run/kamiwaza-offline-extension-gate.sh
sudo chmod 0700 /run/kamiwaza-offline-extension-gate.sh
sudo install -d -o root -g root -m 0700 "$(dirname "${GATE_ATTEMPT_DIR}")"
sudo mkdir -m 0700 "${GATE_ATTEMPT_DIR}"
sudo systemd-run \
  --no-block \
  --service-type=oneshot \
  --remain-after-exit \
  --unit="${GATE_UNIT%.service}" \
  --property=KillMode=process \
  --property=Delegate=yes \
  --property=TimeoutStartSec=infinity \
  /bin/bash /run/kamiwaza-offline-extension-gate.sh "${RUN_ID}" "${GATE_ATTEMPT}"
printf 'record unit=%s attempt_dir=%s\n' "${GATE_UNIT}" "${GATE_ATTEMPT_DIR}"
)

sudo tail -F "${GATE_ATTEMPT_DIR}/console.log"

After the unit is terminal, require the retained unit tuple and the matching durable receipt:

export RUN_ID="<release-or-run>"
export GATE_ATTEMPT=1
export GATE_UNIT="kamiwaza-offline-extension-gate-${RUN_ID}-attempt${GATE_ATTEMPT}.service"
export GATE_ATTEMPT_DIR="/var/lib/kajiya-reports/offline-install/${RUN_ID}/gate-attempts/attempt${GATE_ATTEMPT}"
export GATE_STATUS="${GATE_ATTEMPT_DIR}/result.rc"

(
set -euo pipefail
test "$(sudo cat "${GATE_ATTEMPT_DIR}/boot-id")" = \
  "$(cat /proc/sys/kernel/random/boot_id)"
GATE_STATE="$(sudo systemctl show "${GATE_UNIT}" \
  -p LoadState -p ActiveState -p SubState -p Result \
  -p ExecMainCode -p ExecMainStatus -p InvocationID)"
printf '%s\n' "${GATE_STATE}"
for expected in \
  LoadState=loaded ActiveState=active SubState=exited \
  Result=success ExecMainCode=1 ExecMainStatus=0; do
  if ! grep -Fxq "${expected}" <<<"${GATE_STATE}"; then
    printf 'deploy-gate unit state gate failed: missing %s\n' "${expected}" >&2
    exit 1
  fi
done
grep -Eq '^InvocationID=.+$' <<<"${GATE_STATE}"
test "$(sudo cat "${GATE_STATUS}")" = 0
)

Also run any Konnectivity or authenticated resource gate in the same validation pack. Record every script's source commit and SHA-256. The temporary child-argv limitation described in the extension-load phase also applies to this helper.

SDK tests, UAT data seeding, DNS publication, and A/B promotion are separate demo or publication phases. They are not required to call the base platform or extension bundle installed.

Reruns, recovery, and diagnostics​

  • Download and part assembly are safely repeatable. The download block removes an unverifiable or unresumable .partial; remove a failed .assembling before retrying assembly. Verify final-target SHA-256 after every transfer.
  • rpm --replacepkgs is intentional. A core installer rerun is not a generic reset: inspect the existing unit, Ansible recap, cluster, registry, and surviving child processes first. Recreate the root-only password file before every core attempt because the launcher removes it on exit.
  • Before staging a different release, archive or remove only the previous release's RPM, numbered wrap chunks, checksum, signature, public key, and extension archive/sidecar, root-staged *.parts.json manifests, and artifacts.tsv from /opt/kamiwaza/prereqs. Never mix release artifact families or broadly delete the packaged prerequisite tree. For an exact-release retry, verify the existing files and reuse them.
  • Use monotonically named units and fresh per-attempt directories. Never reuse an attempt number or overwrite a terminal receipt, log, or recap before the cause is understood. After preserving evidence, stop a retained unit to release its systemd state. If a launcher was killed before its exit trap, confirm that its unit and children have stopped, then remove its exact /run/kamiwaza-admin-extra-vars-<run>-attempt<n>.json file before retrying.
  • Reuse a verified pre-extracted extension root. Do not select among stale directories with an unordered search.
  • Do not blindly rerun an extension or deploy-gate phase after interruption. First compare its persistent log, stored and visible catalog state, local manifests, and API resources. If catalog import completed, reconcile it instead of creating duplicates. If the deploy gate stranded its test deployment, remove that exact deployment through the supported API before a new attempt.
  • An SSM disconnect does not stop a system unit. A host reboot does remove all transient units and every contract, secret, and launcher under /run. A missing durable result.rc after reboot is interrupted/unknown, never success. Inspect partial state, recreate /run inputs, and allocate a new attempt. A pre-reboot result.rc of 0 is usable only with its saved recap and fresh post-reboot health and provenance gates.
  • Never delete clusters, PVCs, registry volumes, or an instance as a default retry. Destructive recovery requires a separate backup and rollback decision.
  • Do not treat repeated red HEAD/manifest-not-found lines from a local registry as fatal by color alone. Determine whether the importer is probing before upload, then use the unit result and final manifest/digest gates.

Useful focused diagnostics:

ROOT_TOOLS=(sudo env \
  PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin \
  HELM_PLUGINS=/usr/local/share/helm/plugins \
  KUBECONFIG=/var/lib/k0s/pki/admin.conf)
sudo systemctl show <unit>.service \
  -p LoadState -p ActiveState -p SubState -p Result \
  -p ExecMainCode -p ExecMainStatus -p InvocationID
sudo journalctl -u <unit>.service -o cat
"${ROOT_TOOLS[@]}" kubectl get nodes -o wide
"${ROOT_TOOLS[@]}" kubectl get pods -A -o wide
"${ROOT_TOOLS[@]}" kubectl get events -A --sort-by=.lastTimestamp
"${ROOT_TOOLS[@]}" helm list -A
sudo podman ps -a
df -hT / /tmp /var/tmp /var/lib /opt

If a preflight aborts at storage_host_prep, /var/lib cannot fit the configured storage image on its actual backing filesystem. Grow or remount that filesystem before retrying; do not treat the abort as a prompt or bypass the preflight.

Keep secrets and full process argument lists out of diagnostic captures. If a password appears in output, treat it as exposed and rotate it through a supported path after the installation is stable.

Next steps​
